Plug in. Charge. Go.
Everything you need to charge safely with your K4. Always read the user manual supplied with your charger before first use.
How to charge
Remove the caps
Take the protective caps off the Type 2 connector and the round adaptor connector.
Fit the right adaptor
Screw the 10A, 15A or 32A adaptor onto the round connector until it's firmly seated, then plug it into the matching outlet.
Select the current
Press the Amp button to choose 6, 8, 10, 13, 16 or 32A. Never select more current than the outlet and circuit are rated for.
Optional: timer or limit
Press Time to set a delay start (30-minute steps, up to 8 hours) or a kWh charge limit (5 to 100 kWh).
Plug into the car
Open your car's charge port and push the Type 2 connector in until it clicks. Charging starts automatically once the K4 confirms the connection.
Watch it charge
The colour screen shows energy delivered (kWh), elapsed time, amps, voltage and power (kW).
Unplug
Stop charging from your car (or unlock it), remove the Type 2 connector, then unplug from the wall. Refit the caps and pack the kit in its bag.
Match the outlet
| Setting | Approx. power* | Use with |
|---|---|---|
| 6A | ≈ 1.4 kW | Reduced rate for shared or lightly rated circuits |
| 8A | ≈ 1.8 kW | Reduced rate for shared or lightly rated circuits |
| 10A | ≈ 2.3 kW | Standard 10A household outlet with the 10A adaptor |
| 13A | ≈ 3.0 kW | 15A outlet with the 15A adaptor |
| 16A | ≈ 3.7 kW | Only where the outlet and circuit are rated for it |
| 32A | up to 7 kW | 32A industrial outlet with the 32A High-Power Adaptor |
*Approximate at 230V single phase. Figures to be confirmed against the final product manual.
Charge safely
- Use a dedicated circuit protected by an RCD wherever possible.
- Outlets used for regular charging, and all 32A outlets, should be installed or checked by a licensed electrician.
- Never use extension leads, power boards or double adaptors.
- Don't use the charger if the cable, plug or connector is damaged.
- Keep the plug and outlet out of standing water and rain.
- Don't force a connector that doesn't fit.
If the screen shows an error, unplug, wait 30 seconds and try again. The full error code table is in the user manual.
